SIP User's Manual 122 Document #: LTRT-65415
MediaPack Series
2. From the 'Profile ID' drop-down list, select the Tel Profile identification number you
want to configure.
3. In the 'Profile Name' field, enter an arbitrary name that enables you to easily identify
the Tel Profile.
4. From the 'Profile Preference' drop-down list, select the priority of the Tel Profile, where
'1' is the lowest priority and '20' is the highest. If both IP and Tel profiles apply to the
same call, the coders and other common parameters (noted by an asterisk in the
description of the parameter TelProfile) of the preferred Profile are applied to that call.
If the Preference of the Tel and IP Profiles is identical, the Tel Profile parameters are
applied.
Note: If the coder lists of both IP and Tel Profiles apply to the same call, only the
coders common to both are used. The order of the coders is determined by the
preference.
5. Configure the Profile's parameters according to your requirements. For detailed
information on each parameter, refer to the description of the "global" parameter.
6. From the 'Coder Group' drop-down list, select the Coder Group (see ''Configuring
Coder Groups'' on page 119) o
r the device's default coder (see ''Configuring Coders''
on page 118) to which you
want to assign the Profile.
7. Repeat steps 2 through 6 to configure additional Tel Profiles (optional).
8. Click the Submit button to save your changes.
9. To save the changes to flash memory, see ''Saving Configuration'' on page 169.
3.3.2.7.4 Configuring IP Profiles
The 'IP Profile Settings' page allows you to define up to nine IP Profiles. You can later
assign these IP Profiles to other configuration entities:
Tel to IP Routing (see ''Configuring Tel to IP Routing'' on page 138)
IP to Hunt Group Routing
Table (see ''Configuring IP to Hunt Group Routing Table'' on
page 142)
IP Group (se
e ''Configuring IP Groups'' on page 103)
The 'IP Profil
e Settings' page conveniently groups parameters according to application to
which they pertain:
Common Parameters: parameters common to all application types
Gateway Parameters: parameters applicable to gateway functionality
Notes:
• For a detailed description of each parameter, refer to its corresponding
"global" parameter (configured as an individual parameter).
• IP Profiles can also be implemented when operating with a Proxy server
(when the parameter AlwaysUseRouteTable is set to 1).
• You can also configure IP Profiles using the ini file table parameter
IPProfile (see SIP Configuration Parameters).
