AudioCodes MediaPack MP-124 User Manual

Version 6.2 419 February 2011
SIP User's Manual 10. Configuration Parameters Reference
Parameter Description
RFC2198PayloadType).
Notes:
 The RTP redundancy dynamic payload type can be
included in the SDP, by using the parameter
EnableRTPRedundancyNegotiation.
 This parameter can also be configured per IP Profile,
using the IPProfile parameter.
Web: Enable RTP Redundancy
Negotiation
[EnableRTPRedundancyNegotiation]
Determines whether the device includes the RTP
redundancy dynamic payload type in the SDP, according to
RFC 2198.
 [0] Disable (default)
 [1] Enable
When enabled, the device includes in the SDP message the
RTP payload type "RED" and the payload type configured
by the parameter RFC2198PayloadType.
a=rtpmap:<PT> RED/8000
Where <PT> is the payload type as defined by
RFC2198PayloadType. The device sends the INVITE
message with "a=rtpmap:<PT> RED/8000" and responds
with a 18x/200 OK and "a=rtpmap:<PT> RED/8000" in the
SDP.
Notes:
 For this feature to be functional, you must also set the
parameter RTPRedundancyDepth to 1 (i.e., enabled).
 Currently, the negotiation of “RED” payload type is not
supported and therefore, it should be configured to the
same PT value for both parties.
Web: RFC 2198 Payload Type
EMS: Redundancy Payload Type
[RFC2198PayloadType]
RTP redundancy packet payload type according to RFC
2198.
The range is 96 to 127. The default is 104.
Note: This parameter is applicable only if the parameter
RTPRedundancyDepth is set to 1.
Web: Packing Factor
EMS: Packetization Factor
[RTPPackingFactor]
N/A. Controlled internally by the device according to the
selected coder.
Web/EMS: Basic RTP Packet Interval
[BasicRTPPacketInterval]
N/A. Controlled internally by the device according to the
selected coder.
Web: RTP Directional Control
[RTPDirectionControl]
N/A. Controlled internally by the device according to the
selected coder.
Web/EMS: RFC 2833 TX Payload
Type
[RFC2833TxPayloadType]
N/A. Use the ini file parameter RFC2833PayloadType
instead.
Web/EMS: RFC 2833 RX Payload
Type
[RFC2833RxPayloadType]
N/A. Use the ini file parameter RFC2833PayloadType
instead.

AudioCodes MediaPack MP-124 Specifications

General

Model	MediaPack MP-124
Category	Gateway
Protocols	SIP, H.323, MGCP
Voice Codecs	G.711, G.723.1, G.726, G.729A/B
Fax Support	T.38
Management	SNMP
Security	TLS/SRTP
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-25 to 70°C
Humidity	10% to 90%, non-condensing
Analog Ports	24 FXS
