Version 6.2 433 February 2011
SIP User's Manual 10. Configuration Parameters Reference
Parameter Description
Web: MWI Source Number
EMS: MWI Source Name
[MWISourceNumber]
Determines the calling party's phone number used in the
Q.931 MWI Setup message to PSTN. If not configured,
the channel's phone number is used as the calling
number.
Digit Patterns The following digit pattern parameters apply only to voice mail applications that use
the DTMF communication method. For the available pattern syntaxes, refer to the CPE Configuration
Guide for Voice Mail.
Web: Forward on Busy Digit Pattern
(Internal)
EMS: Digit Pattern Forward On Busy
[DigitPatternForwardOnBusy]
Determines the digit pattern used by the PBX to indicate
'call forward on busy' when the original call is received
from an internal extension.
The valid range is a 120-character string.
Web: Forward on No Answer Digit
Pattern (Internal)
EMS: Digit Pattern Forward On No
Answer
[DigitPatternForwardOnNoAnswer]
Determines the digit pattern used by the PBX to indicate
'call forward on no answer' when the original call is
received from an internal extension.
The valid range is a 120-character string.
Web: Forward on Do Not Disturb Digit
Pattern (Internal)
EMS: Digit Pattern Forward On DND
[DigitPatternForwardOnDND]
Determines the digit pattern used by the PBX to indicate
'call forward on do not disturb' when the original call is
received from an internal extension.
The valid range is a 120-character string.
Web: Forward on No Reason Digit
Pattern (Internal)
EMS: Digit Pattern Forward No Reason
[DigitPatternForwardNoReason]
Determines the digit pattern used by the PBX to indicate
'call forward with no reason' when the original call is
received from an internal extension.
The valid range is a 120-character string.
Web: Forward on Busy Digit Pattern
(External)
EMS: VM Digit Pattern On Busy External
[DigitPatternForwardOnBusyExt]
Determines the digit pattern used by the PBX to indicate
'call forward on busy' when the original call is received
from an external line (not an internal extension).
The valid range is a 120-character string.
Web: Forward on No Answer Digit
Pattern (External)
EMS: VM Digit Pattern On No Answer
Ext
[DigitPatternForwardOnNoAnswerExt]
Determines the digit pattern used by the PBX to indicate
'call forward on no answer' when the original call is
received from an external line (not an internal extension).
The valid range is a 120-character string.
Web: Forward on Do Not Disturb Digit
Pattern (External)
EMS: VM Digit Pattern On DND External
[DigitPatternForwardOnDNDExt]
Determines the digit pattern used by the PBX to indicate
'call forward on do not disturb' when the original call is
received from an external line (not an internal extension).
The valid range is a 120-character string.
Web: Forward on No Reason Digit
Pattern (External)
EMS: VM Digit Pattern No Reason
External
[DigitPatternForwardNoReasonExt]
Determines the digit pattern used by the PBX to indicate
'call forward with no reason' when the original call is
received from an external line (not an internal extension).
The valid range is a 120-character string.
Web: Internal Call Digit Pattern
EMS: Digit Pattern Internal Call
[DigitPatternInternalCall]
Determines the digit pattern used by the PBX to indicate
an internal call.
The valid range is a 120-character string.
Web: External Call Digit Pattern
EMS: Digit Pattern External Call
[DigitPatternExternalCall]
Determines the digit pattern used by the PBX to indicate
an external call.
The valid range is a 120-character string.
