1 Mk8 MM Overview, Specifications and Wiring

Mk8 MM Manual Page | 27

3P-

0V supply to TDS probe

3T+, 3T-

Digital communication connections from TDS probe

1P+

+9V supply to capacitance probe 1

1P-

0V supply to capacitance probe 1

1T+, 1T-

Digital communications connections from capacitance probe 1

2P+

+9V supply to capacitance probe 2

2P-

0V supply to capacitance probe 2

2T+, 2T-

Digital communications connections from capacitance probe 2

FO1

First Out annunciation line voltage input 1

FO2

First Out annunciation line voltage input 2

FO3

First Out annunciation line voltage input 3

FO4

First Out annunciation line voltage input 4

FO5

First Out annunciation line voltage input 5

FO6

First Out annunciation line voltage input 6

FO7

First Out annunciation line voltage input 7

FO8

First Out annunciation line voltage input 8

FO9

First Out annunciation line voltage input 9

FO10

First Out annunciation line voltage input 10

FO11

First Out annunciation line voltage input 11

FO12

First Out annunciation line voltage input 12

Power feed 2A output (230V/110V)

FO13

First Out annunciation line voltage input 13

FO14

First Out annunciation line voltage input 14

FO15

First Out annunciation line voltage input 15

HAI

External high water auxiliary input

1AI

External 1

low water auxiliary input

2AI

External 2

low water auxiliary input

M/R

System alarm mute/reset

TST

System test alarm inputs/ shunt switch (selectable via expansion option 21)
