AUTOFLAME Mk8 MM User Manual

1 Mk8 MM Overview, Specifications and Wiring
Mk8 MM Manual Page | 28
NC
Unused – do not connect
TB
Switched neutral – top blowdown contactor
TBI
Switched neutral – drives top blowdown servomotor clockwise
1LV
Switched neutral – 1
st
low water visual alarm
H1A
Switched neutral – 1
st
low/ high water audible alarm
2LV
Switched neutral – 2
nd
low water visual alarm
2LA
Switched neutral – 2
nd
low water audible alarm
HWV
Switched neutral – High water visual alarm
BB
Switched neutral – Bottom blowdown contactor
BFW
Switched neutral – Feed water pump contactor
MVI
Switched neutral – drives feed water servomotor clockwise
MVD
Switched neutral – drives feed water servomotor counter clockwise
TBD
Switched neutral – drives top blowdown servomotor counter clockwise
DCI
Switched neutral – drives draught control servomotor clockwise
DCD
Switched neutral – drives draught control servomotor counter clockwise

AUTOFLAME Mk8 MM Specifications

General

Brand	AUTOFLAME
Model	Mk8 MM
Category	Controller
Language	English
