AUTOFLAME Mk8 MM User Manual

2 Options & Parameters
Mk8 MM Manual Page | 40
Opt. # Default Range Description
22
0
EGA: O
2
Lower Limit Offset
If the current O
2
value is below this offset limit from the commissioned
value, an alarm/ warning (see option13) will occur, for option 12 set to 3.
0
Disabled
1 – 100
0.1% - 10.0% O
2
23
0
EGA: CO
2
Lower Limit Offset
If the current CO
2
value is below this offset limit from the commissioned
value, an alarm/ warning (see option 13) will occur, for option 12 set to 3.
0
Disabled
0 – 100
0.1% - 10.0% CO
2
24
-
Unused
25
0
EGA: O
2
Absolute Limit
If the current O
2
value is below this absolute limit, an alarm/ warning (see
option13) will occur, for option 12 set to 3.
0
Disabled
1 – 200
0.1% - 20.0% O
2
26
0
EGA: CO
2
Absolute Limit
If the current CO
2
value is above this absolute limit, an alarm/ warning
(see option13) will occur, for option 12 set to 3.
0
Disabled
1 – 200
0.1% - 20.0% CO
2
27
0
EGA: CO Absolute Limit
If the current CO value is above this absolute limit, an alarm/ warning (see
option13) will occur, for option 12 set to 3.
0
Disabled
1 – 200
1 – 200 ppm CO
28
20
EGA: Trim Threshold
The trim threshold is an offset from the required setpoint; if the actual
value is below this offset, then the EGA will not trim. This option should be
set to 0 if trim is to be effective at all times during firing, and/or if external
modulation is optioned. No single point changes can be made if the actual
value is below this trim threshold.
0 – 50
O
C,
O
F, PSI or 0.1 bar or 0.01 bar for low pressure sensor (depends on
load detector set in option 1 and metric/imperial units set in parameter 40)
29
0
MM: Golden Start
Golden start allows an optimum ignition position to be set in the fuel-air
curve,
which is not necessarily low flame or part of the standard
modulating index. Parameter 15 sets how long golden start position is
maintained and from which point to start counting down.
0
Disabled
1
Enabled. Time counted from point of main flame
2
Enabled. Time counted from ignition
30
50
DTI: Minimum Remote Setpoint (DTI/ Modbus/External)
If a required value command is received from the DTI or Modbus that is
below this minimum remote setpoint value, then it will be ignored by the
MM. The MM will continue to fire to meet the previous required setpoint.
5 – 9990
O
C,
O
F, PSI or 0.1 bar or 0.01 bar for low pressure sensor (depends on
load detector set in option 1 and metric/imperial units set in parameter 40)
