AUTOFLAME Mk8 MM User Manual

2 Options & Parameters
Mk8 MM Manual Page | 41
Opt. # Default Range Description
31
100
DTI: Maximum Remote Setpoint (DTI/ Modbus/External)
If a required value command is received from the DTI or Modbus that is
above this maximum remote setpoint value, then it will be ignored by the
MM. The MM will continue to fire to meet the previous required setpoint.
5 – 9990
O
C,
O
F, PSI or 0.1 bar or 0.01 bar for low pressure sensor (depends on
load detector set in option 1 and metric/imperial units set in parameter 40)
32
20
EGA: Trim Delay
After ignition, the EGA does not sample for the time delay set in this option
(if EGA is set to 2 or 3). This allows for the combustion to stabilise before
sampling commences. The delay timer starts at the ignition point.
0 – 250
Seconds
33
1
DTI: MM Identification
Each MM within a sequencing/ DTI/ Modbus/ twin burner loop must be set
with an individual ID number. For communications between the MMs,
there cannot be more than 1 MM with the same ID number.
1 – 10
ID number
34
-
Unused
35
10
DTI: Sequence Scan Time
This is the time period between sequencing requests from the lead and
the lag MMs. On the sequence scan time, the lead MM will demand lag
burners to be brought online or offline, depending on load requirements.
See parameters 86 and 87 for change down and up thresholds. Accurate
fuel flow metering must be entered for sequencing to operate. The MMs
must be connected using data cable (Belden 9501) screened at one end.
1 – 100
Minutes
36
0
EGA: (Mk7 Only) Sensor Selection
This option selects if the Mk7 EGA is fitted with additional cells.
0
No optional sensor
1
NO
2
optioned
2
SO
2
optioned
3
NO
2
and SO
2
optioned
37
0
PID: Derivative Time
The time taken to add/ remove an additional 10% to the firing rate based
on the actual value and the required value.
0
Disabled
1 – 200
Seconds
38
2
PID: Derivative Deadband
This deadband is the margin above and below the required setpoint in
which no derivative control occurs.
0
Disabled
1 - 15
O
C,
O
F, PSI or 0.1 bar or 0.01 bar for low pressure sensor (depends on
load detector set in option 1 and metric/imperial units set in parameter 40)
39
-
Unused
