AUTOFLAME Mk8 MM User Manual

2 Options & Parameters
Mk8 MM Manual Page | 46
Opt. # Default Range Description
72
0
MM: Continuous Pilot Shut Off Threshold
If continuous pilot is enabled (see option/ parameter 111), then if the
actual value is higher than the combined burner switch-off offset (option
10) and this offset above the required setpoint in continuous pilot firing, the
burner will go off.
0
Disabled
1 – 1000
O
C,
O
F, PSI or 0.1 bar or 0.01 bar for low pressure sensor (depends on
load detector set in option 1 and metric/imperial units set in parameter 40)
73
0
MM: VSD Channel 5 Purge Position
0
Purge at Maximum Output
1
Purge at Minimum Output
74
0
MM: VSD Channel 6 Purge Position
0
Purge at Maximum Output
1
Purge at Minimum Output
75
100
MM: Purge Motor Travel Speed
If the speed of the motor is too fast, then decrease the value.
10 – 100
0.1 – 10.0
76
0
EGA: Trim Channel
If an EGA is optioned, then trim can be applied to either channel 2
servomotor or channel 5 VSD. For setting 1, options 91 to 98 must be set.
0
Trim on Channel 2
1
Trim on Channel 5
77
0
MM: VSD Channel 5 Output at Closed
0
Maximum Output at Closed
1
Minimum Output at Closed
78
0
MM: VSD Channel 6 Output at Closed
0
Maximum Output at Closed
1
Minimum Output at Closed
79
0
MM: Terminal T93 Function
0
Warming Stat
1
Night setback
80
0
MM: Outside Temperature Compensation
0
Outside Temperature Compensation Disabled
1
Outside Temperature Enabled using OTC unit
2
Outside Temperature Enabled using MM sensor
81
90
MM: Setpoint at Minimum Outside Temperature
This setpoint is limited by the load detector set in option 1.
50 – 999
O
C,
O
F, PSI or 0.1 bar or 0.01 bar for low pressure sensor (depends on
load detector set in option 1 and metric/imperial units set in parameter 40)
82
30
MM: Minimum Outside Temperature
0 – 145
Value 30 = -10
O
C or -10
O
F (see parameter 40)
83
80
MM: Setpoint at Maximum Outside Temperature
This setpoint is limited by the load detector set in option 1.
50 – 999
O
C,
O
F, PSI or 0.1 bar or 0.01 bar for low pressure sensor (depends on
load detector set in option 1 and metric/imperial units set in parameter 40)
84
80
MM: Maximum Outside Temperature
0 – 145
Value 80 = 40
O
C or 40
O
F (see parameter 40)
