I/O-Box type 6753-xx
125
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
Output extension module 8D0/2, 0A, type 6753-112
Dimensions (W x H x D)
55 x 85 x 58 mm
Power consumption
(logic circuit)
0.325 W
Weight
1.5 N (= 0.15 kg)
Max. current per output
at signal 1
< 1 A (up to +60 °C)
Total load capability 8 A (-20…+60
°C)
