Chapter 4: Operating the GENIUS Compact
Operators & Maintenance Manual GENIUS Compact Version UK 0.1 © BESTnv
BESTnv Industrial Research BV, Marinus van Meelweg 20, 5657 EN, EINDHOVEN, THE NETHERLANDS
General tel. +31 (40) 292 2622 - Service tel. +31 (40) 292 2620 - Fax. +31 (40) 292 2633 - Email: service.BESTnv@bestnv.com
6. Control Voltage button
Use this button to switch on the control current. This enables power supply to all secondary parts of the
GENIUS Compact and immediately switches on the lighting for the optical systems.
This button must be activated in order to be able to start the Belt, the Infeed Shaker and/or the Return
System.
Whenever the Emergency stop has been used, or an “Alarm Out” warning is given, the control current
is automatically switched off.
7. Belt button
Use this button to start/stop the belt, without starting or stopping any other part or the sorter itself.
To be able to start the Belt, the Control Voltage button must be activated.
8. Vibrator Button
Push this button to start/stop the infeed shaker, without starting or stopping any other part or the sorter
itself.
To be able to start the shaker, the Control Voltage button must be activated.
9. Return System
Push this button to start/stop the return system, without starting or stopping any other part or the sorter
itself.
To be able to start the return system, the Control Voltage button must be activated.
10. Production Line switch: Man / 0 / Auto
With this switch the command mode of the sorter installation can be changed.
In Man (manual) mode, all buttons on the control panel above the touchscreen can be used to switch
any component on and/or off.
In Auto (automatic) mode, none of the buttons can be used to switch any component on and/or off. All
these command functions are transferred to the control panel of the production line.
In 0 (deactivated) mode, the control panel cannot be used, not manually and not through the production
line control panel.
11. Program-switch button
This button is used to switch the touchscreen function from Pollux program to Xyclops program.
12. FSV button
(Only present with Full Surround View/Bottom unit System)
Push this button to switch the Full Surround View module ON or OFF.
To be able to start the FSV system, the Control Voltage button must be activated.
