Device Manager Device Settings
The Device Settings widget displays the properties and settings for the control of the devices connected
to the Charging Stations. Each device type (Beacon, TimeKeeper, Router) has unique settings and
properties. The Device Settings widget for each device type displays different settings.
When a device is selected in the Main Panel, the Device Settings widget will display the preset settings
by default.
Device Settings for a Beacon
To open device settings widget for a Beacon
In the Main Panel, click on the Beacon that you want to select.1.
Result: The Device Settings widget displays the settings of the selected Beacon.
Selected Device: The type and ID number of the selected Beacon.
Serial Number: The serial number of the selected Beacon.
Product Info: The additional information or name that was set to identify the selected Beacon.
To change the settings in device setting for a Beacon
On the Preset Beacon scroll box, click on the arrow and select the Preset Beacon number (or type a1.
new number, from 1-85).
Click Apply.2.
Result:
The default Beacon settings based on the selected Preset Beacon are applied to the
selected Beacon. Preset Beacon settings contain Beacon ID, Wireless Channel, Subnet,
LED Brightness, and other system level settings.
Current Preset displays the current preset settings under a preset Beacon ID (i.e. 3,
Calibration), or Custom when the settings of the Beacon were changed and currently
do not match a Preset Beacon.
Select the Calibration Beacon checkbox if the selected Beacon should be programmed as a3.
calibration unit. A Calibration Beacon automatically transmits signal packets faster.
Note: To unassign a Beacon as a Calibration Beacon, clear the checkbox and re-apply the
Preset Beacon.
On the Beacon ID scroll box, click the arrows and select a Beacon ID number (or type a new4.
number, from 1-85) if you want to customize the ID of the Beacon.
Click Apply.5.
Result: The Beacon ID number is changed and the Current Preset displays Custom.
On the Wireless Channel scroll box, click the drop-down list and select the Wireless Channel6.
number if you want to change the previously assigned Wireless Channel.
Click Apply.7.
Result: The Wireless Channel is changed and the Current Preset displays Custom.
On the Subnet scroll box, click the arrows and select the wireless Subnet number (or type a new8.
