Brooks Firetracker FT128 CIE - Page 89

Technical / Programming Manual
FT128 Rev 2.2
89
42. The control expression is true (output activated) when any disablement exists
in the system
93
.
Other
43. The control expression is true (output activated) when LED "Fire brigade TX" is lit,
i.e. when any "Fire brigade TX" output is activated (default) or when a
programmable input with trigger condition "Activated Routing Equipment" is
activated
95
.
44. The control expression is true (output activated) when LED "Fault TX activated" is
lit, i.e. when the routing equipment output (Fault TX) is activated
96
.
45. Output activated when one or more faults are generated in the system
97
.
46. Output activated for loss of mains (in the CIE or external power supply 3366AU).
Note: The output(s) will be activated immediately but the corresponding fault is
normally delayed (set via EBLWin).
47. The control expression is true (output activated) for 5 seconds, whenever a reset
pulse is sent to the specified Zone-Address.
48. Output activated when the specified time channel is activated.
49. Output activated when Alert annunciation alarm is activated (by any alarm point
set to activate this function)
98
. For more information, see FT128 Operation Manual.
50. Output activated when Alert annunciation alarm is activated (by any alarm point
set to activate this function)
98
and acknowledged. For more information, see FT128
Operation Manual.
51. Output activated for Door open in the FT128
99
.
52. This trigger condition plus the OR operator has to be used for each detector (Zone-
Address) controlling a fire door (normally > two detectors). Type of output is
normally "Control, neutral". See Fire Door Closing Function, page 99.
53. Output activated when Service signal is activated (by any sensor)
100
.
54. The control expression is true (output activated) when the control unit standard
output "Fire brigade TX" is activated.
Note: Normally used with output type Routing equipment (Fire brigade TX).
55. Output activated for Door open in the control unit
99
.
56. Output activated when input trigger condition "Extinguishing system fault" is true.
57. Output activated when input trigger condition "Extinguishing system released" is
true.
58. Output activated when input trigger condition "Activated key cabinet" is true.
59. Output activated when one or more faults are generated in the control unit
97
60. Output activated when one or more faults are generated in the control unit
97
.
61. Output activated when one or more faults are generated in the specified Zone
97
.
62. Output activated when the specified external fault is generated
97
.
95
This output will also be activated when the routing equipment test is performed via menu H1. This trigger condition must not
be used for type of output "Routing equipment (Fire brigade TX)".
96
Which is indicated by LED Routing equipment "Fault TX activated". This output will also be activated when the routing
equipment test is performed via menu H1.
97
Which is indicated by LED Fault / Disablements "General fault" and/or LED Routing equipment "Fault TX activated".
98
Valid until the AA alarm is reset or becomes a normal fire alarm.
99
Which is indicated by the LED "Door open" in the CIE
100
Indicated by the LED "Service" in the CIE
