Cisco 8811 Administration Guide

DescriptionItem
•
In IPv4-only mode, displays only the DHCPv4 state, such as DHCP
BOUND.
•
In IPv6-mode, displays only the DHCPv6 state, such as ROUTER
ADVERTISE.
•
DHCPv6 state information is displayed.
DHCP state (IPv4 / IPv6)
The following tables describe the messages that appear for DHCPv4 and DHCPv6 states.
Table 35: DHCPv4 ethernet statistics messages
DescriptionDHCPv4 state
CDP is not bound or WLAN is not in serviceCDP INIT
DHCPv4 is BOUNDDHCP BOUND
DHCPv4 is disabledDHCP DISABLED
DHCPv4 is INITDHCP INIT
DHCPv4 is INVALID; this is initial stateDHCP INVALID
DHCPv4 is RENEWINGDHCP RENEWING
DHCPv4 is REBINDINGDHCP REBINDING
DHCPv4 is init-rebootDHCP REBOOT
DHCPv4 is requestingDHCP REQUESTING
DHCPv4 is RESYNCHDHCP RESYNC
DHCPv4 is bootingDHCP WAITING COLDBOOT TIMEOUT
Unrecognized DHCPv4 stateDHCP UNRECOGNIZED
Duplicated IPv4 AddressDISABLED DUPLICATE IP
DHCPv4 TimeoutDHCP TIMEOUT
Phone is in IPv6-only mode with IPv4 Stack turned
off
IPV4 STACK TURNED OFF
Illegal IPv4 state and should not happenILLEGAL IPV4 STATE
Cisco IP Phone 8800 Series Administration Guide for Cisco Unified Communications Manager
210
Cisco IP Phone Status

Cisco 8811 Specifications

General

Ethernet Ports	2 x 10/100/1000
Lines Supported	5
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Wi-Fi	No
Resolution	800 x 480 pixels
PoE	Yes, IEEE 802.3af Class 2
Audio Codec Support	G.711, G.722, G.729, iLBC
Protocols	SIP
Display	5-inch, 800 x 480 pixels
Headset Jack	RJ9
Weight	1.1 kg
