Cisco 8811 Administration Guide

DescriptionItem
Indicates whether the phone forwards packets that are transmitted and received on
the network port to the access port.
Span to PC port
Indicates whether the phone can participate in video calls when it connects to an
appropriately equipped camera.
Video capability
enabled
Indicates whether the phone allows a device that is attached to the PC port to access
the Voice VLAN.
Voice VLAN
enabled
VLAN that identifies and removes 802.1P/Q tags from packets that are sent to the
PC.
PC VLAN enabled
Identifies if the phone automatically selects a line when the phone goes off hook.Auto line select
enabled
DSCP IP classification for call control signaling.DSCP protocol
control
DSCP IP classification for any phone configuration transfer.DSCP for
configuration
DSCP IP classification for phone-based services.DSCP for services
Security mode that is set for the phone.Security mode
(nonsecure)
Indicates whether web access is enabled (Yes) or disabled (No) for the phone.Web access enabled
Indicates if the SSH port has been enabled or disabled.SSH access enabled
Indicates whether CDP support exists on the switch port (default is enabled).
Enable CDP on the switch port for VLAN assignment for the phone, power
negotiation, QoS management, and 802.1x security.
Enable CDP on the switch port when the phone connects to a Cisco switch.
When CDP is disabled in Cisco Unified Communications Manager, a warning is
presented, indicating that CDP should be disabled on the switch port only if the phone
connects to a non-Cisco switch.
The current PC and switch port CDP values are shown on the Settings menu.
CDP: SW Port
Indicates whether CDP is supported on the PC port (default is enabled).
When CDP is disabled in Cisco Unified Communications Manager, a warning is
displays to indicate that disabling CDP on the PC port prevents CVTA from working.
The current PC and switch port CDP values are shown in the Settings menu.
CDP: PC Port
Indicates whether Link Layer Discovery Protocol Media Endpoint Discovery
(LLDP-MED) is enabled on the switch port.
LLDP-MED:SW
Port
Cisco IP Phone 8800 Series Administration Guide for Cisco Unified Communications Manager
223
Cisco IP Phone Web Page

Cisco 8811 Specifications

General

Ethernet Ports	2 x 10/100/1000
Lines Supported	5
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Wi-Fi	No
Resolution	800 x 480 pixels
PoE	Yes, IEEE 802.3af Class 2
Audio Codec Support	G.711, G.722, G.729, iLBC
Protocols	SIP
Display	5-inch, 800 x 480 pixels
Headset Jack	RJ9
Weight	1.1 kg
