Cisco ASR 1000 Configuration Guide

27-13
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide
OL-14127-08
Chapter 27 Classifying and Scheduling Packets for ASR 1000 Series
Information About Ingress Classification
SUMMARY STEPS
1. enable
2. configure terminal
3. ingress-class-map index-id
4. map mpls all queue
5. map mpls exp exp-value queue strict-priority
6. exit
7. interface {POS | Serial} interface-path-id
8. plim qos input class-map index-id
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Enables privileged EXEC mode. Enter your password when
prompted.
Step 2
configure terminal
Example:
Router# configure terminal
Enters global configuration mode.
Step 3
ingress-class-map 1
Example:
Router(config-ing-class-map)#
Enters the ingress classification template settings for the
specified template ID and enables configuration of the
classifications for IPv4, IPv6, or MPLS.
Step 4
map mpls all queue strict-priority
Example:
Router(config-ing-class-map)# map mpls all
queue strict-priority
Sets the priority for all MPLS packets as high priority.
Step 5
map mpls exp exp-value queue strict-priority
Example:
Router(config-ing-class-map)# map mpls exp 1
queue strict-priority
Classifies MPLS packets with EXP value 1 as high.
Step 6
exit
Example:
Router(config-ing-class-map)# exit
Exits the ingress-class-map mode and goes back to the
global configuration mode.

Cisco ASR 1000 Specifications

General

Operating System	Cisco IOS XE
Interfaces	10 Gigabit Ethernet
Power Supply	AC or DC
Number of Total Expansion Slots	Varies by model
Management Port	Console
Redundant Power Supply Supported	Yes
Width	17.5 inches
Memory	Varies by model
Storage	Varies by model
Dimensions (H x W x D)	Varies by model
Weight	Varies by model
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	5% to 95% non-condensing
MTBF	Varies by model
Redundancy	Redundant power supplies, fans, and route processors (depending on model)
