Chapter 27 Classifying and Scheduling Packets for ASR 1000 Series
Information About Ingress Classification
Step 7
interface {POS | Serial} interface-path-id
Example:
Router(config)# interface POS 0/2/0
Enters the interface configuation mode and specifies the
POS or Serial interface name with the notation
slot/sub-slot/interface-id. Possible interface types for this
procedure are:
• POS
• Serial
Note The example indicates a 0 port in the POS SPA
adapter at sub-slot 2 in the SIP at slot 0.
Step 8
plim qos input class-map index-id
Example:
Router(config-if)# plim qos input class-map 1
Attaches the ingress classification class-map template with
the specified index-id to the POS or Serial interface.
Command or Action Purpose
