Chapter 2 Catalyst 3550 Switch Cisco IOS Commands
show mls qos maps
---------------------------------------
0 : 00 00 00 00 00 00 00 00 01 01
1 : 01 01 01 01 01 01 02 02 02 02
2 : 02 02 02 02 03 03 03 03 03 03
3 : 03 03 04 04 04 04 04 04 04 04
4 : 05 05 05 05 05 05 05 05 06 06
5 : 06 06 06 06 06 06 07 07 07 07
6 : 07 07 07 07
Dscp-switch priority map:
d1 : d2 0 1 2 3 4 5 6 7 8 9
---------------------------------------
0 : 00 00 00 00 00 00 00 00 00 00
1 : 00 00 00 00 00 00 01 01 01 01
2 : 01 01 01 01 01 01 01 01 01 01
3 : 01 01 02 02 02 02 02 02 02 02
4 : 02 02 02 02 02 02 02 02 03 03
5 : 03 03 03 03 03 03 03 03 03 03
6 : 03 03 03 03
Cos-dscp map:
cos: 0 1 2 3 4 5 6 7
--------------------------------
dscp: 0 8 16 24 32 40 48 56
IpPrecedence-dscp map:
ipprec: 0 1 2 3 4 5 6 7
--------------------------------
dscp: 0 8 16 24 32 40 48 56
Dscp-dscp mutation map:
Default DSCP Mutation Map:
d1 : d2 0 1 2 3 4 5 6 7 8 9
---------------------------------------
0 : 00 01 02 03 04 05 06 07 08 09
1 : 10 11 12 13 14 15 16 17 18 19
2 : 20 21 22 23 24 25 26 27 28 29
3 : 30 31 32 33 34 35 36 37 38 39
4 : 40 41 42 43 44 45 46 47 48 49
5 : 50 51 52 53 54 55 56 57 58 59
6 : 60 61 62 63
Note The d1 column specifies the most-significant digit in the internal DSCP; the d2 row specifies the
least-significant digit in the internal DSCP. The intersection of the d1 and d2 values provides the
policed-DSCP, the CoS, the switch priority, or the mutated-DSCP value. For example, in the
DSCP-to-CoS map, an internal DSCP value of 43 corresponds to a CoS value of 5.
Related Commands Command Description
mls qos map Defines the CoS-to-DSCP map, DSCP-to-CoS map, DSCP-to-DSCP-mutation
map, IP-precedence-to-DSCP map, and the policed-DSCP map.
