Comet Synertia RF - Table 32: Example 2 - Structure of the Request; Table 33: Example 2 - Structure of the Response

User Manual Synertia® RF Generator 95
The information contained in this manual is subject to change by Comet Yxlon without prior notice.
Example 2
Example 2 shows the data transferred for a read command for parameter 8021 (0x1F55)
'Forward power'. The response from the generator contains a 4-byte integer value as
data. In this case the forward power is 0 W.
Header
Command Number
Data
Byte
Number
1
2
3
4
5
6
Name /
Description
Address
(0x0A fixed)
Function Code
(0x41 = read)
Command ‘Forward Power’
(0x1F55 = 8021)
Data (always 0x0001 for
read command)
Example
Value
0x0A
0x41
0x1F
0x55
0x00
0x01
Table 32: Example 2 – Structure of the request
Header
Data
Byte Number
1
2
3
4
5
6
7
Name /
Description
Address
(0x0A fixed)
Function Code
(0x41 = read)
Length
(0x04 = 4
bytes)
4 bytes data
(4
-byte integer value 0x00000000 = 0 W)
Example
Value
0x0A
0x41
0x04
0x00
0x00
0x00
0x00
Table 33: Example 2 – Structure of the response
