40 User Manual Synertia® RF Generator
The information contained in this manual is subject to change by Comet Yxlon without prior notice.
4.2 Connecting ground for equipotential
bonding
The generator is classified as protection class 1 equipment and requires a protective earth
connection. This line is part of the mains cable.
The ground connector on the back of the generator housing must be used to provide an
appropriate ground connection to the ground of the system for equipotential bonding.
WARNING
To avoid any dangerous situations during connecting to AC mains, the
ground connection must be established first during installation.
Safety note 24: Warning - grounding
Figure 17: Ground connector air-cooled unit Figure 18: Ground connector water-cooled unit
