Comet Synertia RF - Table 19: Operating Status

60 User Manual Synertia® RF Generator
The information contained in this manual is subject to change by Comet Yxlon without prior notice.
LED
Status
Description
AC On
LED off
The
Synertia® RF generator is switched off or no AC mains
power is present.
LED on (green)
The Synertia® RF generator is switched on, AC mains power is
present.
RF On
LED off
RF output power is switched off.
LED on (green)
RF
output power is switched on.
Interlock
LED off
The interlock chain is interrupted. RF power operation is
disabled.
A warning or error code has been generated.
LED on (green)
This is the normal
status during operation. The interlock chain
is closed
, and the system works as expected.
Power Limit
LED off
This is the normal status during operation. The RF
output
power meets the set point.
LED on (yellow)
The RF
output power is switched on but does not meet the set
point. The generator has reached the forward or reflected
power limit or operates under any power derating condition.
A warning code has been generated.
Over Temp.
LED off
This is the normal status during operation.
The
Synertia® RF generator operates within the specified
temperature range.
LED on (yellow)
The
Synertia® RF generator has exceeded the specified
temperature range. The generator has turned off the RF
output power. An error code has been generated.
General Alarm
LED off
This is the normal status during operation. The system works as
expected.
LED on (yellow)
An internal error, apart from overtemperature, has occurred.
An error code has been generated.
Table 19: Operating status
INFORMATION
Detailed error information can be retrieved via the communication interface by using
the corresponding commands (see section 10.3 "List of parameters" on page 102and
section 10.4 “ Reading warning and error messages” on page 110).
