12 User Manual Synertia® RF Generator
The information contained in this manual is subject to change by Comet Yxlon without prior notice.
• For overcurrent protection provide an external circuit breaker to AC (Mains) input,
according to the following values:
Rated RF
Input voltage Max. current Circuit breaker B characteristics
5 kW 208-480 V, 3-phase 3x 22 A 25 A 3 times limiting current for
1.5 kW 208-240 V, single phase 11 A 16 A 3 times limiting current for
Table 5: Values of external circuit breaker
• Install and operate this device with a disconnect switch that conforms to the
applicable requirements. The switch must be easily accessible and near the device.
• Use only shielded cables (coaxial) on the RF output connector.
• Use shielded cables wherever it is applicable.
• Ensure that all cables are properly connected.
• Install the AC line cord so that it is fixed.
• Whenever the RF generator is connected to the customer’s system, any applicable
interlock circuitry must be connected to the generator in a way which under all
circumstances disables the power source as soon as the interlock chain is
interrupted.
Do not disable, bypass, or modify the interlock chain of the generator partially or
completely.
• Always ensure that all hazard labels on the housing are present and legible.
WARNING
Failure to comply may result in serious injury or death to the user
and may be a serious breach of local regulations.
Safety note 8: Warning - safe installation
