Comet Synertia RF - Table 36: Structure of a Request Via RS-232 with CRC16 Checksum; Table 37: Structure of a Response to a Read Command Via RS-232

98 User Manual Synertia® RF Generator
The information contained in this manual is subject to change by Comet Yxlon without prior notice.
Header
Command Number
Data
C
RC16
Byte
Number
1
2
3
4
5
…
n
(
≤ 253)
n + 1
n + 2
(
≤ 255)
Name
Address
Function
Code
Command
Number
Between 1 and 249 bytes of
data
CRC16 checksum
Description
0x0A
(fixed)
0x41 or
0x42
High
Byte
Low
Byte
D1
…
Dx (max.
249)
Calculated over
bytes
number 1 to n
Table 36: Structure of a request via RS-232 with CRC16 checksum
Response via RS-232
Header
Data
CRC16
Byte
Number
1
2
3
4
…
n
(
≤ 252)
n + 1
n + 2
(
≤ 254)
Name
Address
Function
Code
Length
Between 0 and 249 bytes of data
CRC16 checksum
Description
0x0A
(fixed)
0x41
(fixed)
Number of
trailing
data bytes
D1
…
Dx
(max. 249)
Calculated over bytes
number 1 to n
Table 37: Structure of a response to a read command via RS-232
