User Manual Synertia® RF Generator 29
The information contained in this manual is subject to change by Comet Yxlon without prior notice.
Sync Layer
No.
Label
Description
Connector
type
Availability
6 Arc-Sync Out/In For connecting and synchronizing the Arc
Detection feature of the Synertia® RF generator
with other generators and/or matching networks
with an Arc Detection feature on the same tool
on-site
Note: Not yet in use!
SMA
coaxial,
female
Optional
7
RDS
Realtime Data Streaming provides raw data of
e. g. forward power and complex gamma values
at high speed
Note: Not yet implemented.
RJ45
Optional
8 Sync. Bus Out/In For connecting several Synertia® RF generators
to act in parallel (e. g. aligned error handling or
synchronized RF on command execution)
Note: Not yet in use!
2 x Display
Port
Optional
Table 12: Interfaces on the backs of air- and water-cooled generators – Sync Layer
Fieldbus Layer
No.
Label
Description
Connector
type
Availability
9 Userport For connecting the Synertia® RF generator
directly to the customer’s system; for additional
information, see section 9.2 “
User Port – 15-pin
analog/digital interface (optional)” on page 76
15-pin
DSUB,
female
Optional
EtherCAT
– PCT
Interface
10
EtherCat®
In/Out
For connecting the Synertia® RF generator to an
existing EtherCAT® system fieldbus
2 x RJ45
Optional
Table 13: Interfaces on the backs of air- and water-cooled generators – Fieldbus Layer
