User Manual Synertia® RF Generator 109

The information contained in this manual is subject to change by Comet Yxlon without prior notice.

Parameter

No.

Parameter

Name

Example

Value

Unit

Type

Enum

Values

Comment /

Description

8132

Error 16 state

int (32 bit)

Actual Values

" Warnings

8150

Number of

warnings

int (32 bit)

Number of present warnings

8167

Warning 1

int (32 bit)

8168

Warning 2

int (32 bit)

8169

Warning 3

int (32 bit)

8170

Warning 4

int (32 bit)

8171

Warning 5

int (32 bit)

8172

Warning 6

int (32 bit)

8173

Warning 7

int (32 bit)

8174

Warning 8

int (32 bit)

8175

Warning 9

int (32 bit)

8176

Warning 10

int (32 bit)

8177

Warning 11

int (32 bit)

8178

Warning 12

int (32 bit)

8179

Warning 13

int (32 bit)

8180

Warning 14

int (32 bit)

8181

Warning 15

int (32 bit)

8182

Warning 16

int (32 bit)

Table 49: Parameters
