108 User Manual Synertia® RF Generator

The information contained in this manual is subject to change by Comet Yxlon without prior notice.

Parameter

No.

Parameter

Name

Example

Value

Unit

Type

Enum

Values

Comment /

Description

8139

Error 7

int (32 bit)

8114

Error 7 state

int (32 bit)

8140

Error 8

int (32 bit)

8116

Error 8 state

int (32 bit)

8141

Error 9

int (32 bit)

8118

Error 9 state

int (32 bit)

8142

Error 10

int (32 bit)

8120

Error 10

state

int (32 bit)

8143

Error 11

int (32 bit)

8122

Error 11 state

int (32 bit)

8144

Error 12

int (32 bit)

8124

Error 12 state

int (32 bit)

8145

Error 13

int (32 bit)

8126

Error 13 state

int (32 bit)

8146

Error 14

int (32 bit)

8128

Error 14 state

int (32 bit)

8147

Error 15

int (32 bit)

8130

Error 15 state

int (32 bit)

8148

Error 16

int (32 bit)
