Example 3: Write set-point (Error)
Example 3 shows the data transferred for a write command for parameter 1206 (0x04B6)
“Power set-point”. The host sends “200.00 (0x00989680 = 10.000 W)” as value. An error
is reported, because the value of 10.000 W is off limit.
In the Function Code, the highest bit is set (Exception Function Code), and the Exception
Code 0x84 is sent.
Address Function Code Parameter Data CRC
0x0A
0x42
0x04 0xB6
0x00 0x098 0x96 0x80
0xC5 0xCA
Table 44: Example 3 - Write set-point - request
Address
Function Code
Exception Code
CRC
0x0A 0xC2 0x84 0x71 0x01
Table 45: Example 3 - Write set-point - response
Example 4: Read status
Example 4 shows the data transferred for a read command for parameter 8000 (0x1F40)
'State'. The response from the generator contains a 4-byte integer value as data. In this
case the value is 1 (0x00000001), which means 'RF off'.
Address Function Code Parameter Data CRC
0x0A 0x41 0x1F 0x40 0x00 0x01 0xFB 0x65
Table 46: Example 4 - Read status - request
Address Function Code Length Data CRC
0x0ARX
0x41
0x04
0x00 0x00 0x00 0x01
0x95 0x11
Table 47: Example 4 - Read status - response
