96 User Manual Synertia® RF Generator
The information contained in this manual is subject to change by Comet Yxlon without prior notice.
Example 3
Example 3 shows the data transferred for a write command for parameter 1001 (0x03E9)
'Command'. The host sends '1' as value which means 'RF on' (see section 10.5 “ Reference
documents” on page 111).
Since this is a write command, the generator echoes the request as response indicating
that the transaction was successful.
Header
Command
Number
Data
Byte Number
1
2
3
4
5
6
7
8
Name /
Description
Address
(0x0A fixed)
Function
Code (0x42
= read)
Command ‘Command’
(0x03E9 = 1001)
Data
(0x0001 = ‘1’ for ‘RF on’)
Example
Value
0x0A
0x42
0x03
0xE9
0x00
0x00
0x00
0x01
Table 34: Example 3 – Structure of the request
Header
Command Number
Data
Byte Number
1
2
3
4
5
6
7
8
Name /
Description
Address
(0x0A fixed)
Function
Code (0x42
= read)
Command ‘Command’
(0x03E9 = 1001)
Data
(0x00000001= ‘1’ for
‘RF on’)
Example
Value
0x0A
0x42
0x03
0xE9
0x00
0x00
0x00
0x01
Table 35: Example 3 – Structure of the response
