50 User Manual Synertia® RF Generator
The information contained in this manual is subject to change by Comet Yxlon without prior notice.
Put hoses on both water connections and push them on all the way.
Figure 29 Attachment of hose
Position the hose clamps and tighten them firmly.
Figure 30 Water Out and Water In properly connected
Water inlet temperature +5 °C (non-condensing) to +35 °C
7 l/min (1.54 gal (US)/min)
Maximum system pressure 0.6 MPa (6 bar)
Table 16: Values of cooling water
Open the stop valve for the water outlet (Water Out) and check the water
connections of the generator for leaks (e. g. formation of drops on the NPT
threads or the attached hoses).
Open the stop valve for the water inlet (Water In) and check the water
connections of the generator for leaks (see previous step).
Check again for leaks after approx. 1 hour after commissioning of the cooling
circuit (recommended).
