User Manual Synertia® RF Generator 33
The information contained in this manual is subject to change by Comet Yxlon without prior notice.
Functional
block
Description
AC mains input
Input for AC mains voltage
AC/DC
converter
Realizes AC/DC conversion and provides DC voltage for RF
stage as well as
auxiliary voltage for the control circuits
Control
Provides interfaces for external communication and realizes RF power control loop
Interfaces
To be used for remote control of
the generator
RF stage
Converts DC from AC/DC converter to corresponding RF power
RF
output
50
Ω coaxial RF output
Table 14: Description of functional blocks of the generator
