User Manual Synertia® RF Generator 79
The information contained in this manual is subject to change by Comet Yxlon without prior notice.
The digital inputs (nominal value 5
V) are configured to recognize a voltage above
V as a
high
state, whereas voltages below 0.8 V are recognized as
low
state.
It is important to consider that all digital inputs are edge triggered.
low
to
high
state or from
high
to
low
will be recognized by the
generator as an event and causes an effect. Maintaining the signal on a continuous
level will have no effect.
-couplers are used on all digital inputs. The source driving the digital input must
be capable of delivering a curr
ent of at least 10 mA.
Each signal like digital and analog in
- and outputs uses a return signal as reference.
For operation, all returns must be grounded either on host or client side.
Table 21: 15-pin User Port – Signal specifications
