The appliance rear panel contains the following elements:
Table 1: C200 Rear Panel Elements
A button used for turning the appliance on and off.
A power jack used for supplying power to the appliance.
Connect the power supply cable provided in the appliance
package to this jack.
A button used for restarting the appliance or resetting it to its
default settings.
For information, see Restarting the CTERA Appliance (on page
332) and Resetting the CTERA Appliance to Its Default Settings
(on page 331).
Two USB 2.0 ports used for connecting USB drives.
Note that you can connect more than two USB drives, by
connecting a powered USB hub. Be sure to use a powered hub,
in order to avoid exceeding the power capacity of the USB
ports.
An Ethernet port used for connecting the appliance to your
Ethernet LAN switch or router.
Connect the Ethernet cable provided in the appliance package
to this port.
For best performance, use a Gigabit-capable Ethernet switch.
The back cover opens to allow insertion of up to two SATA 3.5"
hard drives.
Do not cover or obstruct the fan grille as it is needed for proper
cooling of your appliance.
USB Eject 1 / USB Eject 2
Buttons used to eject the USB drives. Each button ejects the
USB drive connected to the port that is adjacent to the button.
After ejecting a USB drive, wait until the USB LED turns off. You
can then safely remove the USB drive from the system.
