CTERA C200 Specifications and Installation 2
CTERA C-Series User Guide 7
The following table explains the C200 front panel LEDs:
Table 2: C200 Front Panel LEDs
LED
State
Explanation
Ready/Status
Short red blink,
followed by a green
blink
The appliance is starting up.
On (Green)
The appliance is operational.
Heartbeat (Red)
The appliance is rebooting.
LAN
On
A link has been established for the LAN port.
Blinking
Data is being transmitted or received.
Cloud
On
The appliance is connected to the CTERA Portal.
Blinking slowly
The appliance is resolving the CTERA Portal address.
Blinking fast
The appliance is connecting to the CTERA Portal.
Off
The appliance is disconnected from the CTERA Portal.
USB 1 /2
On
A USB storage device is attached.
Off
No USB storage device is attached, or the USB storage
device has been successfully ejected and may be
unplugged.
Disk Fail
On
An array has failed.
Blinking fast
A disk has failed.
Blinking slowly
An array is degraded.
Heartbeat
A disk is unhealthy.
Off
There are no disk failures.
Disk 1 / 2
On (Green)
A disk is installed in the SATA bay.
Blinking (Green)
The disk is in use.
On (Orange)
The disk format is unrecognized. The disk should be
formatted.
