CTS FOS-3126-PLUS SERIES User Manual

31
[ip_option]
Specify IP option bit.
“any”: Specify “any” to denote the
value which is either 0 or not 0.
“0”: Specify “0” to indicate that the
IPv4 is 5 bytes.
“1”: Specify “1” to indicate that the
IPv4 header is bigger than 5 bytes.
Switch(config-acl-RULE)#
frame-type ipv4 [dest_mac]
[protocol_id] [source_ip]
[ip_mask] [dest_ip]
[ip_mask] [ip_ttl]
[ip_fragment] [ip_option]
[dest_mac]
Define destination MAC address type.
“any”: Specify “any” to apply ACL rule
to any destination MAC addresses.
“uc”: Specify “uc” to apply ACL rule to
unicast traffic.
“mc”: Specify “mc” to apply ACL rule
to multicast traffic.
“bc”: Specify “bc” to apply ACL rule to
broadcast traffic.
[protocol_id]
This parameter is to show the protocol
number defined in the protocol field of
the IPv4 packet. Specify “any” to
denote any protocols; specify “1-255”
to denote different defined protocols.
[source_ip]
This is sender IP filtering function.
Specify “any” to filter frames from any
sender IP addresses. Or, specify either
a host IP address or a network address
(x.x.x.x).
[ip_mask]
Define source IP mask.
“any”: Specify “any” to mean any IP
mask.
“255.255.0.0”: Specify a specific IP
mask.
[dest_ip]
This is destiantion IP filtering function.
“any”: Specify “any” to filter frames to
any target IP addresses.
“x.x.x.x”: Specify a host IP.
[ip_mask]
Define destination IP mask.
“any”: Specify “any” to mean any IP
mask.
“255.255.0.0”: Specify a specific IP
mask.
[ip_ttl]
Specify IP TTL bit.
