4.4.6.1 MAC Table Learning
Click the option MAC Table Learning from the MAC Address Table menu and then the following
screen page appears.
Auto: Enable port MAC address learning.
Disabled: Disable port MAC address learning.
4.4.6.2 Static MAC Table Configuration
Click the option Static MAC Table Configuration from the MAC Address Table menu and then
the following screen page appears.
NOTE: The Managed Switch only supports switch-based MAC security and does not
support port-based MAC security. The Managed Switch can support up to 128 entries of
MAC security list.
Click New to add a new MAC address entity and then the following screen page appears.
Click Edit to view and edit the selected MAC address entity.
Click Delete to remove a MAC address entity.
