4.5.13.2 SFP Port State
SFP Port State displays each port’s slide-in SFP Transceiver information e.g. the currently
detected temperature, voltage, TX Bias, etc.. Select SFP Port State from the SFP Information
menu and then the following screen page appears.
Port: The number of the SFP module slide-in port.
Temperature (C): The operation temperature of slide-in SFP module currently detected.
Voltage (V): The operation voltage of slide-in SFP module currently detected.
TX Bias (mA): The operation current of slide-in SFP module currently detected.
