CTS FOS-3128 Series User Manual

96
2.6.21 Switch Command
Switch command
Parameter
Description
Switch(config)# switch bpdu 00-
0F [permit]
[permit]
Permit packets from the address
ranging from 0180C2000000 to
0180C200000F.
Switch(config)# switch bpdu 20-
2F [permit]
[permit]
Permit packets from the address
ranging from 0180C2000020 to
0180C200002F.
Switch(config)# switch bpdu 10
[permit]
[permit]
Permit packets from the address
0180C2000010.
Switch(config)# switch mtu [1518-
9600]
[1518-9600]
Specify the maximum frame size
in bytes. The allowable MTU
value is between 1518 and 9600
bytes.
Switch(config)# switch statistics
polling port [1-28]
[1-28]
Specify the number of ports for
data acquisition in each polling.
Switch(config)# switch statistics
polling interval [1-600]
[1-600]
(Unit:1/10secs)
Specify the time interval between
each polling.
No command
Switch(config)# no switch bpdu 00-0F
Undo permit packets from the
address ranging from
0180C2000000 to
0180C200000F.
Switch(config)# no switch bpdu 20-2F
Undo permit packets from the
address ranging from
0180C2000020 to
0180C200002F.
Switch(config)# no switch bpdu 10
Undo permit packets from the
address 0180C2000010.
Switch(config)# no switch mtu
Reset MTU size back to the
default. (9600 bytes)
Switch(config)# no switch statistics polling port
Reset the number of ports for
data acquisition in each polling
back to the default. (10 ports)
Switch(config)# no switch statistics polling interval
Reset the time interval between
each polling back to the default.
(60 in 1/10 seconds)
Show command
Switch(config)# show switch bpdu
Show the current BPDU
configuration.
Switch(config)# show switch mtu
Show the current the maximum
frame size configuration.
Switch(config)# show switch statistics
Show the current configuration of
polling port number and time
interval between each polling.
