CTS FOS-3128 Series User Manual

29
Switch(config-acl-RULE)#
source-ipv4 any
Specify source IPv4 address as “ANY”.
Switch(config-acl-RULE)#
source-ipv4 address
[A.B.C.D] [0-255.X.X.X]
[A.B.C.D]
Specify source IPv4 address.
[0-255.X.X.X]
Specify source IPv4 mask.
Switch(config-acl-RULE)#
source-ipv6 any
Specify source IPv6 address as “ANY”.
Switch(config-acl-RULE)#
source-ipv6 address
[A:B:C:D:E:F:G:H]
[10~128]
[A:B:C:D:E:F:G:H]
Specify source IPv6 address.
[10~128]
Specify source IPv6 prefix-length.
Switch(config-acl-RULE)#
source-l4-port any
Specify source Layer4 port as “ANY”.
Switch(config-acl-RULE)#
source-l4-port [1-65535]
[0xWXYZ]
[1-65535]
Specify source Layer4 port.
[0xWXYZ]
Specify source Layer4 mask.
(Range:0x0000~FFFF)
Switch(config-acl-RULE)#
source-mac any
Specify source MAC as “ANY”.
Switch(config-acl-RULE)#
source-mac mac
[xx:xx:xx:xx:xx:xx]
[ff:ff:ff:00:00:00]
[xx:xx:xx:xx:xx:xx]
Specify source MAC.
[ff:ff:ff:00:00:00]
Specify source MAC mask.
Switch(config-acl-RULE)#
tos [any | 0xWX]
[any | 0xWX]
Specify IPv4 TOS and IPv6 traffic class
(Range: 0x00~FF) or “ANY”.
Switch(config-acl-RULE)#
vid [any | 1-4094]
[any | 1-4094]
Specify 802.1q VLAN ID (Range:
1~4094) or “ANY”.
No command
Switch(config)# no acl [1-
192]
[1-192]
Remove the specified ACL rule.
Switch(config-acl-RULE)#
no action
Reset action back to the default
(permit).
Switch(config-acl-RULE)#
no action-port
Reset copy(mirror)-to/redirect-to port
back to the default (Port 1).
Switch(config-acl-RULE)#
no destination-ipv4
Reset destination IPv4 address back to
the default (ANY).
Switch(config-acl-RULE)#
no destination-ipv6
Reset destination IPv6 address back to
the default (ANY).
Switch(config-acl-RULE)#
no destination-l4-port
Reset destination Layer4 port back to
the default (ANY).
Switch(config-acl-RULE)#
no destination-mac
Reset destination MAC back to the
default (ANY).
Switch(config-acl-RULE)#
no ingress-port
Reset ingress port(s) back to the
default (ANY).
Switch(config-acl-RULE)#
no ethertype
Reset Ethertype back to the default
(ANY).
