CTS FOS-3128 Series User Manual

61
Switch(config)# show
l2protocol-tunnel clear
Clear each PDU’s encapsulation and
decapsulation counters of all ports.
Examples of L2PT command
Switch(config)# l2protocol-tunnel
Enable L2PT function.
Switch(config)# l2protocol-tunnel cos 3
Specify the priority bit value “3” to L2PT
Class of Service (CoS).
Use “Interface” command to configure Layer 2 protocol data units (PDUs) settings.
L2PT & Interface command
Parameter
Description
Switch(config)# interface [port_list]
[port_list]
Enter several discontinuous port
numbers separated by commas or a
range of ports with a hyphen. For
example:1,3 or 2-4
Switch(config-if-PORT-PORT)#
l2protocol-tunnel
Enable layer 2 protocol tunneling for
CDP, LLDP, STP and VTP packets on
the selected port(s).
Switch(config-if-PORT-PORT)#
l2protocol-tunnel cdp
Enable layer 2 protocol tunneling for
CDP packets on the selected port(s).
Switch(config-if-PORT-PORT)#
l2protocol-tunnel lldp
Enable layer 2 protocol tunneling for
LLDP packets on the selected port(s).
Switch(config-if-PORT-PORT)#
l2protocol-tunnel point-to-point
Enable point-to-point layer 2 protocol
tunneling for LACP, PAgP and UDLD
packets on the selected port(s).
Switch(config-if-PORT-PORT)#
l2protocol-tunnel point-to-point
lacp
Enable point-to-point layer 2 protocol
tunneling for LACP packets on the
selected port(s).
Switch(config-if-PORT-PORT)#
l2protocol-tunnel point-to-point
pagp
Enable point-to-point layer 2 protocol
tunneling for PAgP packets on the
selected port(s).
Switch(config-if-PORT-PORT)#
l2protocol-tunnel point-to-point
udld
Enable point-to-point layer 2 protocol
tunneling for UDLD packets on the
selected port(s).
Switch(config-if-PORT-PORT)#
l2protocol-tunnel stp
Enable layer 2 protocol tunneling for
STP packets on the selected port(s).
Switch(config-if-PORT-PORT)#
l2protocol-tunnel vtp
Enable layer 2 protocol tunneling for
VTP packets on the selected port(s).
No command
Switch(config-if-PORT-PORT)# no
l2protocol-tunnel
Disable layer 2 protocol tunneling for
CDP, LLDP, STP and VTP packets on
the selected port(s).
Switch(config-if-PORT-PORT)# no
l2protocol-tunnel cdp
Disable layer 2 protocol tunneling for
CDP packets on the selected port(s).
Switch(config-if-PORT-PORT)# no
l2protocol-tunnel lldp
Disable layer 2 protocol tunneling for
LLDP packets on the selected port(s).
Switch(config-if-PORT-PORT)# no
l2protocol-tunnel point-to-point
Disable point-to-point layer 2 protocol
tunneling for LACP, PAgP and UDLD
packets on the selected port(s).
Switch(config-if-PORT-PORT)# no
l2protocol-tunnel point-to-point
lacp
Disable point-to-point layer 2 protocol
tunneling for LACP packets on the
selected port(s).
