Introduction
2
DSM0400 Fixed Mount Area Imager Bar Code Reader
custom configuration can be accomplished by scanning the programming
bar codes within this guide.
Programming can also be performed using the protocol “Decoded Engine
Se
rial Protocol” (DESP) or using Datalogic Aladdin™ Configuration applica-
tion, downloadable from the Datalogic website. This multi-platform utility
pr
ograms allow device configuration using a PC. It communicates with the
device using a serial or USB cable and can also create configuration barcodes
to print.
Overview
Chapter 1, Introduction: provides a product overview, information about
Technical Support and manual.
Chapter 2, Setup: presents information about unpacking and setting up the
scanner, and interface configuration bar codes and details.
Chapter 3, Configuration Using Bar Codes: provides instructions and bar
code labels for customizing your scanner. There are different sections for
int
erface types, default factory settings, general features, data formatting
and symbology specific features.
Chapter 4, References: provides details concerning programmable features.
Appendix A Technical Specifications: lists physical and performance charac-
teristics, as well as environ
mental and regulatory specifications. It also pro-
vides standard cable-pin-ou
ts and descriptions of the functions and
behaviors of the scanner’s LED and Speaker indicators.
Appendix B Sample Bar Codes: offers sample bar codes of several common
symbologies.
Appendix C Keypad: includes numeric bar codes to be scanned
for certain
parameter settings.
Manual Conventions
The following conventions are used in this document:
The symbols listed below are used in this manual to notify the reader of key
issu
es or procedures that must be observed when using the reader:
NOTE
Notes contain information necessary for properly diagnosing,
repairing an
d operating the reader.
CAUTION
The CAUTION symbol advises you of actions that
could damage
equipment or property.
