Enter/Exit Programming
Mode
92
DSM0400 Fixed Mount Area Imager Bar Code Reader
Code 39 Quiet zones
This feature specifies the
number of quiet zones for Code 39 la
bels. Quiet
zones are blank areas at the ends of a ba
r code, typically 10 times the width of
the narrowest ba
r or space in the label
.
Read the Enter/Exit Progra
mming Mod
e bar code at th
e top of this page and
then one of the foll
owing bar codes.
DEF
A
UL
T
Quiet zones = Auto
Quiet Zones = Small Quiet Zone
s on two side
99
101
