Enter/Exit Programming Mode
Product Reference Guide 127
Datalogic 2 of 5 Set Length 1
This feature specifies one of the barcode lengths for Datalogic 2 of 5. Length 1
is the minimum label length if in
Variable Length on page 111 Mode, or the first
fixed length if in
Fixed Length on page 111 Mode. The length includes the bar-
code’s check and data characters. The length can be set from 2 to 50 charac-
ters. For more detailed programming instructions see, "Set Length" on
Chapter
4, References
.
Table 11 provides some examples for setting Length 1.
Table 11. Datalogic 2 of 5 Length 1 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
2 Characters 6 Characters 14 Characters 50 Characters
2
Pad with leading zeroes to
yield two digits
02 06 14 50
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT Datalogic 2 of 5 LENGTH 1 SETTING
5
Scan Two Characters From
Appendix C
‘0’ and ‘2’ ‘0’ and ‘6’ ‘1’ and ‘4’ ‘5’ AND ‘0’
6 Scan ENTER/EXIT PROGRAMMING MODE
Select Datalogic 2 of 5 Length 1 Setting
Make a mistake? Scan the CANCEL barcode to abort and
not save the entry string. You can then start again at the
beginning.
CANCEL
DEFAULT
01 = Length 1 is 1 Characters
