Product Reference Guide 5
Chapter 2
Setup
Unpacking
Check carefully to ensure the device and any cables or accessories ordered are
present and undamaged. If any damage occurred during shipment, contact
""
on
page 3.
KEEP THE PACKAGING. Should the unit ever require service, it should be
re
turned in its original shipping container.
Setting Up the Scanner
Figure 1 Cable Connection/Disconnection to the Scanner (DSM049X only)
Paper clip
Insert/Remove cable
connector
Follow the steps provided in this section to connect and get your scanner up
and communicating with its host:
1. (DSM049X Models only) IMPORTANT: First of all, connect the Datalogic Inter-
face Cable (not included - to be selected among the possible accessories) to the
scan
ner as shown in Figure 1. To insert/remove the cable, insert a paper clip or
similar object into the opening shown.
2.Connect the other end to the Host (see the next section
Connect Host
Interface on page 6
, and Figure
2
).
3.Modify
Customizing Configuration Settings on page 12
(only if modifications are
needed from factory settings).
