Enter/Exit Programming Mode
Product Reference Guide 155
MSI Set Length 1
This feature specifies one of the barcode lengths for MSI. Length 1 is
the minimum label length if in
Variable Length on page 93
Mode, or the first
fixed length if in
Fixed Length on page 93
Mode. Length includes the bar-
code’s data characters only. The length can be set from 01 to 50 char-
acters. For more detailed programming instructions see, "Set Length"
on
Chapter 4, References
.
Table 21
provides some examples for setting Length 1.
Table 21. MSI Length 1 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
01 Characters 07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT MSI LENGTH 1 SETTING
4
Scan Two Characters From
Appendix C
‘0’ and ‘1’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select MSI Set Length 1 Setting
Make a mistake? Scan the CANCEL barcode to abort and
not save the entry string. You can then start again at the
beginning.
CANCEL
01 = Length 1 is 1 Character
To Next Page
