Code 11 Set Length 2

This feature specifies one of the barcode lengths for Code 11. Length 2 is the

maximum label length if in

Variable Length on page 93

Mode, or the second fixed

length if in

Fixed Length on page 93

Mode. Length includes the barcode’s check

and data characters.

The length can be set from 2 to 50 characte

rs. A setting of 0 specifies to ignore

this length (only one fixed length). For more detailed programming instructions

see "Set Length" on

Chapter 4, References

Table 16

provides examples for setting Length 2.

Table 16. Code 11 Length 2 Setting Examples

STEP ACTION EXAMPLES

Desired Setting (pad with

leading z

eroes)

00 (Ignore This

Length)

07 Characters 15 Characters 50 Characters

2 Scan ENTER/EXIT PROGRAMMING MODE

3 Scan SELECT CODE 11 LENGTH 2 SETTING

Scan Two Characters From

Appendix C

‘0’ and ‘0’ ‘0’ and ‘7’ ‘0’ and ‘F’ ‘3’ AND 2’

5 Scan ENTER/EXIT PROGRAMMING MODE

Select Code 11 Length 2 Setting

Make a mistake? Scan the CANCEL barcode to abort and

not save the entry string. You can then start again at the

beginning.

CANCEL

DEFAULT

50 = Length 2 is 50 Characters
