Enter/Exit Programming Mode
Product Reference Guide
55
Global AIM ID
NOTE
This feat
ure enables/di
sables additi
on
of AIM IDs for all symbology t
ypes.
AIM label identifiers (as o
pposed to custom characters
you select yourse
lf as
with label identifiers) can be includ
ed with scanned bar code data. See
"Global
AIM ID"
on
Chapte
r 4, Referenc
es
for more detailed programming instru
ctions.
DEF
A
UL
T
Global AIM ID = Disable
Global AIM ID = Enable
62
64
