Enter/Exit Programming
Mode
100
DSM0400 Fixed Mount Area Imager Bar Code Reader
CODE 39 CIP (FRENCH PHARMACEUTICAL)
The following o
ptions apply to the Co
de 39 CIP symbology.
Code 39 CIP Enable/Disable
Enables/Disables ability of the read
er to decode Code
39 CIP labels.
DEF
A
UL
T
Code 39 CIP = Disable
Code 39 CIP = Ena
ble
107
109
