Enter/Exit Programming
Mode
80
DSM0400 Fixed Mount Area Imager Bar Code Reader
EAN 13 (JAN 13)
The following
options apply to
the EAN 13 (Jan
13) symbology.
EAN 13 Enable/Disable
When disabled, the reader will not read EAN 13/JAN 13
barcodes.
EAN 13 = Disable
EAN 13 = Enable
DEF
A
UL
T
EAN 13 Check Character Transmission
Enable this option to transmit the ch
eck character al
ong with EAN 13 ba
rcode
data.
EAN 13 Check Character Transmissi
on = Don’t Send
EAN 13 Check Character Tr
ansmission = Send
DEF
A
UL
T
87
89
