Code 128 Set Length 2

This feature specifies one of the barcode lengths for Code 128. Length 2 is the

maximum label length if in

Variable Length on page 93

Mode, or the second fixed

length if in

Fixed Length on page 93

Mode. Length includes the barcode’s data

characters only.

The length can be set from 1 to 80 characte

rs. A setting of 0 specifies to ignore

this length (only one fixed length). For more detailed programming instruc-

tions, see "Set Length" on

Chapter 4, References

Table 4

provides examples for setting Length 2.

Table 4. Code 128 Length 2 Setting Examples

STEP ACTION EXAMPLES

1 Desired Setting

00 (Ignore This

Length)

07 Characters 15 Characters 80 Characters

2 Scan ENTER/EXIT PROGRAMMING MODE

3 Scan SELECT CODE 128 LENGTH 2 SETTING

Scan Two Characters From

Appendix C

‘0’ and ‘0’ ‘0’ and ‘7’ `1' and `5' `8' and `0'

5 Scan ENTER/EXIT PROGRAMMING MODE

Select Code 128 Length 2 Setting

Make a mistake? Scan the CANCEL barcode to abort and

not save the entry string. You can then start again at the

beginning.

CANCEL

DEFAULT

80 = Length 2 is 80 Characters
