Plessey Set Length 1

This feature specifies one of the barcode lengths for

Plessey Length Control on

page 159

. Length 1 is the minimum label length if in

Variable Length on page 93

Mode, or the first fixed length if in

Fixed Length on page 93

Mode. Length

includes the barcode’s data characters only. The

length can be set from 01 to

50 characters. For more detailed programming instructions see, "Set Length" on

Chapter 4, References

Table 23

provides some examples for setting Length 1.

Table 23. Plessey Length 1 Setting Examples

STEP ACTION EXAMPLES

1 Desired Setting

01 Characters 07 Characters 15 Characters 50 Characters

2 Scan ENTER/EXIT PROGRAMMING MODE

3 Scan SELECT Plessey LENGTH 1 SETTING

Scan Two Characters From

Appendix C

‘0’ and ‘1’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’

5 Scan ENTER/EXIT PROGRAMMING MODE

Select Plessey Set Length 1 Setting

Make a mistake? Scan the CANCEL barcode to abort and

not save the entry string. You can then start again at the

beginning.

CANCEL

DEFAULT

01 = Length 1 is 1 Character

Datalogic DSM0400 User Manual
