Enter/Exit Programming
Mode
78
DSM0400 Fixed Mount Area Imager Bar Code Reader
Expand UPC-E to UPC-A
Expands UPC-E data to
the UPC-A da
ta format.
DEF
A
UL
T
UPC-E to UP
C-A = Don’t Expa
nd
UPC-E to UPC-A = Expand
UPC-E Number System Character Transmission
This feature enables/disables transmi
s
sion of the UPC-E system number char
-
acter.
UPC-E Number System Character =
Do not transmit
UPC-E Number System Characte
r = Transmit
DEF
A
UL
T
85
87
